Stealth Black Small Block Chrysler 273-318-340-360 Serpentine Conversion Kit
Air Conditioning and Alternator
All Inclusive WRAPTORTM 8 Track Serpentine System for Small Block Chrysler engines with 140 Amp alternator and Peanut Style AC compressor. CVF Racing's 8 Rib Serpentine pulleys increase grip, reduce stretching and prevent slippage compared to traditional 6 Rib designs. Spring loaded Gates tensioner ensures proper tension during hard acceleration and deceleration while compensating for belt stretch. Places alternator on the driver's side above the power steering pump.
All Inclusive Kit Includes:
- High Flow Aluminum Water Pump
- 140 Amp Black 1-Wire CS130 Alternator
- Plated AC Compressor
- AC Compressor Clutch Cover
- Gates Premium Green Strip 8 Rib Belt
- Water Pump Pulley & Cover
- Crank Pulley
- Crank Pulley Spacer
- Alternator Pulley & Cover
- One Piece Billet Aluminum Bracket
- Universal Alternator Fan
Application Notes:
- Upgrade to Power Steering Only Requires Pump, PS Pulley and Belt Purchase.
- Works with either Mechanical or Electric fuel Pump
- Works with either Mechanical or Electric fan (may require long fan spacer)
- Requires Lower Radiator Hose on Passenger Side
If ordering without accessories, please call 651.356.8593 before ordering and see the requirements below:
- Alternator - GM CS130 Style Alternator with 6-12 O'clock mounting and 6.6" bolt spacing
- Compressor - Peanut Style (7B10) Compressor with 8 Rib Clutch
- Water Pump - 5.7" Tall, Clockwise Rotation, 5/8" Pilot and Lower Radiator Hose on Driver Side
